APM-7099
APM-7099
Marki Microwave
0.01GHz – 20GHz Low Phase Noise Amplifier
The APM-7099 is a broadband distributed, low phase noise driver amplifier designed to provide a saturated +25 dBm output power with low DC power consumption. This amplifier uses GaAs HBT technology for low phase noise, and is optimized to drive our NLTL multiplier line. It can also provides sufficient power to drive the LO port of an S-diode mixer from 10 MHz to 15 GHz or of an H or L diode mixer from 10 MHz to 20 GHz. This amplifier can be operated with a variety of bias conditions for both low power and high-power applications.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | 0.01 |
| Minimum Input Power for Saturation [dBm] | +10 |
| Maximum Input Power for Saturation [dBm] | +16 |
| Saturated Output Power [dBm] | +25 |
| Small Signal Gain [dB] | 14 |
| OIP3 [dBm] | +24 |
| Amplifier Type | LO Driver Bare Die/Modules |
| Package | Bare Die and Module |
