Marki Microwave
0.09 - 6 GHz High Dynamic Range Gain Block
The ADM-8350PSM is a high-linearity, low noise amplifier capable of providing +22 dBm output power up to 6 GHz. The ADM-8350PSM can serve either as a linear signal amplifier, or as a saturated driver amplifier for H- or S-diode mixers. The amplifier has excellent return losses, gain flatness, and high IP3. The ADM-8350PSM is similar to the ADM-8095. The main difference is that the IP3 is higher for the ADM-8350.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | 0.09 |
| Minimum Input Power for Saturation [dBm] | +2 |
| Maximum Input Power for Saturation [dBm] | +6 |
| Saturated Output Power [dBm] | +22 |
| Small Signal Gain [dB] | 23 |
| OIP3 [dBm] | +39.5 |
| Amplifier Type | LO Driver Surface Mounts |
| Package | Surface Mount |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
