AMM-9025CH
AMM-9025CH
Marki Microwave
0.01 - 65GHz mmWave GaAs Driver Amplifier
Wideband Distributed Low Noise Amplifier 14dB
The AMM-9025CH is a wideband distributed low noise amplifier capable of providing 14 dB gain from 10MHz to 65 GHz and a low 2.8 dB typical noise figure from 7 to 30GHz. The ADM-9025CH is an ideal linear signal amplifier for applications requiring low power consumption and small form-factors.
AMM-9025CH is DC coupled with the low end limited by the blocking capacitors. The amplifier has excellent return losses and gain flatness in a small wire bondable 1.75 x 1.2 mm die.
AMM-9025CH Applications:
- Test and Measurement Equipment
- SATCOM
- LO signal chain for mmWave mixers
- Radar
- Electronic warfare equipment
- Aerospace and Defence
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Minimum Frequency | 0.0001 GHz |
| OIP3 [dBm] | +26 |
| Package | Bare Die |
| Product Family | Amplifiers |
| Size | 1.75x1.2mm |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
