APM-6849
APM-6849
Marki Microwave
GaAs Broadband Low Phase Noise Amplifier
The APM-6849 is a single stage broadband, low phase noise LO driver amplifier designed to provide saturated +21 dBm output power. This amplifier uses GaAs HBT technology for low phase noise, and provides industry leading ‑170 dBc/Hz at 10 kHz offset from carrier frequency. The amplifier is also highly efficient with 21% peak PAE at 5 GHz input frequency and low DC current draw. It is optimized to provide enough power to drive the LO port of an S-diode mixer (2 – 20 GHz) and an H/L-diode mixer (2 - 32 GHz). This amplifier is operational with a variety of bias conditions for both low and high-power applications.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | 2 GHz |
| Minimum Input Power for Saturation [dBm] | +10 |
| Maximum Input Power for Saturation [dBm] | +15 |
| Saturated Output Power [dBm] | +21 |
| Small Signal Gain [dB] | 11 |
| OIP3 [dBm] | +21 |
| Amplifier Type | LO Driver Bare Die/Modules |
| Package | Bare Die and Module |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
