MILTECH 907
MILTECH 907
Enercon Technologies Europe
Compact, military-grade managed Ethernet switch with single D-Type 44 Pin connector - 5 Ports
The MILTECH 907 is a MIL-STD, fully managed military-grade network switch offering 5 triple-speed (10/100/1000Mbps) ports.
The MILTECH 907 enables interconnectivity of network devices and data transmission in military platforms with one high-density D-Type 44 pin connector. It can be remotely managed to optimize communications and prioritise critical information traffic. Advanced network features, never before found in a package of this size, include switching protocols, virtual LANS (VLANS), traffic prioritisation (QoS), and bandwidth aggregation are standard.
The MILTECH 907’s gigabit speeds and 24VDC power make it instantly compatible with network device and power systems. Its mechanical packaging enhancements, including High-Density D-Type 44 pin connector, is designed for MIL-STD-810F airborne and ground environmental compliance and high reliability.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Type | Managed Ethernet Switch |
| Total Number of Ports | 2-5 |
| Power Input | 24VDC (16 - 36VDC), 5W |
| Designed to Meet |
|
| Port Configuration | 5 x 10/100/1000M Copper |
| Operating Temperature | -45°C to 85°C |
| Dimensions | 113mm X 54mm X 40mm |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
