DSOX3052A
DSOX3052A
Keysight Technologies
InfiniiVision 3000 X-Series 500MHz Oscilloscope with 2 Analogue Channels
Make measurements you can trust - Keysight 3000T X-Series oscilloscopes deliver high-end technology in a smaller form factor, with an extremely intuitive touch user interface. With an industry-leading waveform update rate, you can capture elusive glitches and anomalies not possible on other oscilloscopes.
Achieve 500 MHz of bandwidth and an immersive signal detail of 1,000,000 waveforms/second update rate with the Keysight DSOX3052A. With the advanced measurement capabilities of the DSOX3052A, Keysight oscilloscopes will help you test more efficiently whilst solving measurement challenges faster and easier. The DSOX3052A provides 2 analogue channels, 4 Mpts memory with an 8.5-inch WVGA display.
Whats Included
- 3-year factory warranty (90 days for unserialized accessories such as passive probes)
- Certificate of calibration, 3-year calibration interval
- Secure erase
- N2843A passive probe 500 MHz 10:1 attenuation, 1 per channel
- Multi-language interface and help: Chinese (simplified), Chinese (traditional), Czech, English, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Thai, and Turkish
- Documentation CD containing localized user guide, service guide, and programmer’s manual
- Localized power cord and overlay
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Form | Digital Storage |
| Range | InfiniiVision |
| Series | 3000A X-Series |
| Bandwidth | 500 MHz |
| ADC Bits | 8 bits |
| Max Memory Depth | 4 Mpts |
| Max Sample Rate | 4 GSa/s |
| Bandwidth Upgrades | Available |
| Display Size | 8.5-inch WVGA display |
| Waveform Update Rate | 1,000,000 wfms/s |
| Channels | 2 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
