Ei-S110

Ei-S110

Advantech

Ei-A110 Edge intelligence system with integrated hardware and software powered by WISE-DeviceOn

main product photo
To fulfill customer requirements in edge computing trend, Advantech offers Ei-A110 Edge Intelligence System integrated hardware plus software solution powered by WISE-DeviceOn. It allows users to incorporate sensor data aggregation, edge analytics, and cloud integration for fast and easy real-time edge intelligence, and plus the flexibility to add on more software modules from the WISE-PaaS marketplace that enable IoT connectivity, data manageability and analytics in the edge.
Contact us for Lead Time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

Request a quote
More Information
Attribute Value
Dimensions 156 x 112 x 28 mm
Operating System Android 6.0
Power 12V/3A
LED Indicators 1 x power
1 x wireless
CPU Arm® Cortex®-A17 quad-core processor (1.6 GHz)
Primary Storage 16 GB of onboard eMMC
Display Max Resolution HDMI 1: Native 4K resolution up to 3840 x 2160 (default 1080p)
HDMI 2: 1920 x 1080 (display only)
LAN 1 x 10/100/1000 Mbps
Mounting VESA (75 x 75)
  • Wall
  • Desktop
  • Pole
  • Magnet
  • DIN rail
HDMI 2
Certifications CCC/BSMI/CE/FCC/UL/CB
Serial Port 1 (RS232/485/422 by jumper)
GPU Mali-T764
Graphics Engine OpenGL ES 1.1/2.0/3.0, OpenCL 1.1, DirectX 11
Additional Storage Optional Micro SD
H/W Video Codec Decoder: 4K 10-bits 60fps H.265, H.264, MPEG-1, MPEG-2, MPEG-4,VC-1, VP8, AVS, MVC
Encoder: 1080P for H.264 ([email protected], MP, [email protected]), MVC and VP8
Mini PCIe 1 (for 4G module option)
M.2 1 (for Wi-Fi module option)
USB 4 x USB 2.0
1 x OTG USB
Audio 1
Micro SD Card Slot 1
Display Orientation Portrait and landscape modes supported
Clinet Status Reports Generates Heartbeat, System reports
Supported media formats


  • JPG
  • PNG
  • BMP
  • GIF

Video

  • H.264
  • MPEG-4
  • MPEG-2

Text

  • Text
  • Scrolling text

Audio

  • MP3
  • AAC
  • PCM
Key Features
  • Built-in Arm® Cortex®-A17 quad-core processor (1.6 GHz)
  • 2 GB onboard memory
  • 16GB eMMC onboard expandable MicroSD (TF) storage
  • Dual HDMI outputs (1 x supports 4K resolution and 1 x supports 1080P resolution)
  • Ultra-compact design for easy installation in confined spaces
  • Supports various mount options including VESA, wall, pole, Magnet, and DIN-rail mounting
  • Can be integrated with optional Wi-Fi, Bluetooth, and 4G LTE modules
  • Equipped with WISE-Paas/SignageCMS software, which supports multi-screen displays
  • Supports Android 6.0
Operating Temperature 0 - 40° C
Software WIDE-Paas/SignageCMD
More Information
Attribute Value
Data Sheet Click here to view
