EMSense 40
ETS-Lindgren
EMSense 40 Electric Field Probe features isotropic sensors, continuous measurement, and USB or fiber optic connectivity to EMCenter platforms for fast data acquisition
EMSense™ 40 Electric Field Probe - 10 kHz to 10 GHz (usable to 12 GHz)
The EMSense 40 Electric Field Probe features advanced isotropic sensor design, low-noise miniaturized electronics, and continuous single-range measurement across its entire dynamic range. It allows data collection for each axis (X, Y, Z) individually or summed, and connects via fiber optic or USB to EMCenter™ platforms for real-time monitoring and data acquisition.
Compatible with EMCenter 1-, 2-, and 7-Slot systems, it provides high-speed communication through an updated CPU and seamless integration with ProbeView™ V software for accurate electric field measurements.
Key Features:
- Laser powered for extended testing
- Frequency corrected field values direct from probe
- No need to apply correction factor
- Single probe frrequency range – 10 MHz to 40 GHz
- Broad dynamic range – 2 to 1000 V/m
- Sleek stalk design nThree axis dipole design
- A2LA Accredited Calibration
- Suitable for MIL Standard Specs:
- MIL-STD 461F Radiated Susceptibility (RS)
- Suitable for Automotive Specs:
- SAE J1113/27 nGMW 3091/3097/3103
- FORD FMC 1278
- Suitable for Commercial Specs:
- EN/ IEC 61000-4-3 Radiated Immunity
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Linearity | ± 0.5 dB ± 0.5 V/m |
| Maximum Frequency | 40 GHz |
| Minimum Frequency | 10 MHz |
| Damage Level | 2,000 V/m |
| Isotropy | ± 0.5 dB @ 1 GHz |
| Frequency Response | ± 1.2 dB (10 MHz - 40 GHz) (with Internal Correction) |
| Frequency Range | 10 MHz to 40 GHz |
| Dynamic Range | 2 to 1,000 V/m |
| Resolution |
0.001 V/m (2 – 10 V/m) |
| Sampling Rate | 100 Measurements/s Maximum (X, Y, Z & ETot) |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
