HI-62213PBI
HI-62213PBI
Holt Integrated Circuits
HI-62213 Series MIL-STD-1553 Drop-In interface solution
The HI-6220xPBx family is a fully integrated and dual redundant MIL-STD-1553 interface solution which includes 1553 protocol, SRAM, dual transceivers and dual isolation transformers in a single BGA package. The device is a direct pin compatible drop-in replacement for the Data Device Corporation (DDC®) Total-ACE® Family of MIL-STD-1553 Terminals.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
HI-62213PBI Specifications
- Dual Redundant MIL-STD-1553A/B/1760 Channel
- BC/RT/MT or RT/MT modes
- Integrated Dual Isolation Transformers
- Direct and/or Transformer Coupled
- Supports Simple System RT Mode
- 64Kx17 or 4Kx16 SRAM
- External RT Address Inputs
- MIL-STD-1760 RT “Auto Boot”
- +3.3V Single Supply
- Built-in Self-Test
- Generic 8/16-bit Processor Interface
- -40°C to +85°C or -55°C to +125°C
- No Limitations on transmit duty cycle
- PBGA-312
- 15.2mm x 27.9mm x 4.7mm
| Attribute | Value |
|---|---|
| RoHS | No |
| Product Type | MIL-STD-1553 Drop-In Replacement ICs |
| Package Description | 312 Pin Plastic BGA |
| Moisture Sensitivity Level | 3.0000 |
| Product Longevity | > 10 years |
| Applications |
|
| Flow | I |
| Theta JA (°C/W): | 30.05 |
| Theta JB (°C/W): | 19.52 |
| Temperature Range | -40°C to +85°C |
