MBAL-0220SM
MBAL-0220SM
Marki Microwave
Passive MMIC Surface Mount Balun (2 GHz - 20 GHz)
The MBAL-0220SM is a GaAs passive MMIC balun in a 4mm QFN surface mount package. Its frequency ranges from 2 to 20 GHz and offers a 1:2 impedance ratio. The 4mm QFN package is a lead free, RoHS compliant package compatible with standard leaded and lead-free solder reflows.
Connectorised evaluation packages are available. The MBAL-0220SM is an excellent choice for balanced amplifiers, clock distribution, and higher order Nyquist sampling in analog to digital converters.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Phase Balance Degrees | 3.0000 |
| Maximum Frequency | 20 GHz |
| Isolation (dB) | 10 |
| Minimum Frequency | 2 GHz |
| Product Type | High Isolation |
| Insertion Loss (dB) | 6.0000 |
| Amplitude Balance (dB) | 0.25 |
| Common Mode Rejection (dB) | 30.0000 |
| RoHS | Y |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
