MBAL-1440CH
MBAL-1440CH
Marki Microwave
MMIC Isolation Balun (14 GHz - 40 GHz)
The MBAL-1440 is a MMIC isolation balun. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional balun technologies.
The MBAL-1440 is available as a wire bondable chip. Low unit to unit variation allow for accurate simulations using the provided S3P file taken from measured production units.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Phase Balance Degrees | 1.1 |
| Maximum Frequency | 40 GHz |
| Isolation (dB) | 13 |
| Minimum Frequency | 14 GHz |
| Product Type | High Isolation |
| Insertion Loss (dB) | 3.0000 |
| Amplitude Balance (dB) | 0.2 |
| Common Mode Rejection (dB) | 35.0000 |
| RoHS | Y |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
