MEQ3-60A
MEQ3-60A
Marki Microwave
Passive MMIC Equaliser (DC - 60 GHz)
The MEQ3-60A is a passive MMIC equaliser. It is a positive gain slope equalizer designed to pass DC to 60GHz. Equalisation can be applied to reduce low pass filtering effects in both RF/microwave and high speed digital systems.
Passive GaAs MMIC technology allows production of smaller equaliser constructions that replace larger form factor circuit board constructions. Better IC tolerances allow for less unit to unit variation than circuit board technologies.
Low unit to unit variation allow for accurate simulations using the provided S2P file taken from measured production units.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Return loss | 15 dB |
| Maximum Frequency | 60 GHz |
| Minimum Frequency | DC |
| RoHS | Y |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
