MIC-710IVA
MIC-710IVA
Advantech
8ch AI Video System on NVIDIA® Jetson Nano™
8ch AI Video System on NVIDIA® Jetson Nano™.
Key Features:
- NVR fan base design
- Embedded with NVIDIA® Jetson NANOTM up to 512 GOPS
- Supports 8 x PoE (IEEE 802.3af), 1 x GbE, 8-ch DIO
- Supports 2 x SATAIII
- Linux OS with board support package (BSP)
- Supports Allxon 24/7 remote monitoring and OTA deployment
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| CPU | Quad Core ARM Cortex A57 |
| GPU | 128 CUDA cores, Performance up to 512 GOPS (FP16) |
| NVIDIA® CPU/GPU | NVIDIA® Jetson Nano™ |
| I/O | 4-ch DI, 4-ch DO |
| Memory | 4GB LPDDR4 |
| Flash | 16GB eMMC |
| Storage | 2 x 3.5" or 2 x 2.5" SATAIII (6Gb/s) drives |
| USB | External: 1 x USB 3.0, 1 x USB 2.0 (Type-A) |
| Power Switch | 1 x Power ON/OFF Switch |
| Serial Ports | 1 x RS485 |
| OTG USB | 1 x Micro USB |
| Display | HDMI (Max. resolution 3840x2160 @ 60Hz) |
| Ethernet | 1 x 10/100/1000 Mbps |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
