MILTECH 610
MILTECH 610
Enercon Technologies Europe
Military-grade fast Ethernet unmanaged 8 port switch with LED indicators
The MILTECH 610 is an 8 x 10/100Mbp unmanaged Fast Ethernet switch with 8 D38999 circular connectors.
Ideal for battlefield C4ISR, voice, video, and sensor data acquisition, and communications in military platforms, the MILTECH 610 serves as a robust fast Ethernet switch for providing unmanaged local area network (LAN) connectivity to IP-enabled computing and net-centric devices. The MILTECH 610 is equipped with 8 LED indicator lights for easy observation of link status on each port.
The MILTECH 610 operates on readily available 24VDC power and supports MIL-STD1275 so that it may be powered directly from any available battery in the field. The unit’s mechanical packaging enhancements include IP76 and MIL-STD-810F airborne and ground environmental compliance for high reliability.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| IP Certified | IP67 |
| Type | Unmanaged Ethernet Switch |
| Total Number of Ports | 6-10 |
| Power Input | 24VDC (18-32VDC), 2.8W |
| Designed to Meet |
|
| Port Configuration | 8 x 10/100M Copper |
| Operating Temperature | -45°C to 85°C |
| Dimensions | 269mm X 133mm X 71.7mm |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
