MM1-0832LSM
MM1-0832LSM
Marki Microwave
GaAs MMIC Double Balanced Mixer
The MM1-0832LSM is a GaAs MMIC double balanced mixer that is optimised for high frequency applications. MM1-0832LSM is a high frequency X band mixer that works well as both an up and down converter through Ka band. This mixer offers low conversion loss and high LO to RF isolations at low LO powers.
The sister MM1-0832HSM is recommended for medium power applications. The MM1-0832LSM is available in a 3x3 mm QFN package. Evaluation boards are available.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Key Features |
|
| Applications |
|
| IF (GHz) | DC to 12 |
| LO Drive Min (dBm) | +8 to +15 |
| Conversion Loss (dB) | 8.5 |
| Isolations L-R (dB) | 36 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| IIP3 (dBm) | +11 |
| Product Type | MMIC/Microlithic Surface Mounts |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
