MM1-1453LSM
MM1-1453LSM
Marki Microwave
GaAs MMIC Double Balanced Mixer
The MM1-1453LSM is a GaAs MMIC double balanced mixer that features excellent conversion loss, superior isolations and spurious performance across a broad bandwidth.
MM1-1453LSM works well as both an up and down converter and is recommend for low power applications that demand high linearity. If a higher LO drive is required, the MM1-1453HSM offers similar specifications in the same surface mount package.
The MM1-1453LSM is available in a 4x4 mm QFN package. Evaluation boards are also available. The AMM-6702SM is recommended as the ideal LO driver for the MM1-1453LSM.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Applications |
|
| IF (GHz) | 0 to 22 |
| LO Drive Min (dBm) | +7 to +15 |
| Conversion Loss (dB) | 8 |
| Isolations L-R (dB) | 56 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| IIP3 (dBm) | +13 |
| Product Type | MMIC/Microlithic Surface Mounts |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
