MMIQ-0520L
MMIQ-0520L
Marki Microwave
Low LO Drive Passive GaAs MMIC IQ Mixer
MMIQ-0520L is a low LO drive, passive GaAs MMIC IQ mixer that operates down to an unrivaled +3 dBm LO drive level. This is an ultra-broadband mixer spanning 5 to 20GHz on the RF and LO ports with an IF from DC to 6 GHz. Up to 40 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid.
Both wire bondable die and Connectorised modules are available.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Applications |
|
| IF (GHz) | DC to 6 |
| LO Drive Min (dBm) | +3 to +13 |
| Conversion Loss (dB) | 9 |
| Isolations L-R (dB) | 46 |
| Isolations L-I (dB) | 49 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| Image Rejection (dB) | 35 |
| Product Type | MMIC Bare Die/Modules |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
