MMQ-40125H
MMQ-40125H
Marki Microwave
GaAs MMIC Millimeter Wave 4x Multiplier
MMQ-40125H is a MMIC millimeter wave 4x multiplier fabricated with GaAs Schottky diodes. MMQ-40125H operates over a 10 to 31.25 GHz input frequency range or a quadrupled output frequency range of 40 to 125 GHz. Operation past 125GHz is pending verification. Contact factory for information.
MMQ40125H is available as a connectorised coaxial module using 1.0 mm connectors on the output. Wire bondable die are also available.
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Applications |
|
| Conversion Loss (dB) | 20 |
| Minimum Input (GHz) | 10 |
| Maximum Input (GHz) | 31.25 |
| Minimum Output (GHz) | 40 |
| Suppression F (dBc) | 19 |
| Suppression 3F (dBc) | 12 |
| Maximum Output (GHz) | 125 |
| RoHS | Y |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
