MQH-1842
MQH-1842
Marki Microwave
MMIC Quadrature Hybrid (18 - 42 GHz)
The MQH-1842 is a MMIC 18GHz – 42 GHz quadrature (90°) hybrid. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional coupler technologies.
The MQH-1842 is available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S4P file taken from measured production units.
Applications include single sideband upconverters, image rejection downconverters, IQ modulators, balanced amplifiers, microwave correlators, and microwave Butler matrices.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| RoHS | Y |
| Key Features |
|
| Isolation | 15 dB |
| Maximum Frequency | |
| Minimum Frequency |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
