MQS-0418
MQS-0418
Marki Microwave
MMIC 90° Splitter / Combiner (4 - 18 GHz)
The MQS-0418 is a MMIC 4GHz – 18GHz 90° splitter/combiner. Wire bondable 50Ω terminations are available on-chip. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional splitter/combiner technologies.
The MQS-0418 is available as a wire bondable chip and connectorised module. Low variation allows for accurate simulations using the provided S4P file taken from measured production units.
Applications include single sideband upconverters, image rejection downconverters, IQ modulators, balanced amplifiers, and microwave correlators. The MQS-0418 is not recommended for applications involving reflected signals.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| RoHS | Y |
| Key Features |
|
| Isolation | 20 dB |
| Maximum Frequency | 18 GHz |
| Minimum Frequency | 4 GHz |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
