FieldFox N9914B - A lightweight, durable, cable and antenna analyzer, spectrum analyzer, network analyzer, and more.

FieldFox Handheld Microwave Analyzer, 6.5 GHz

Keysight's FieldFox portable analyzers are equipped to handle your toughest working environments during routine maintenance, in-depth troubleshooting, and anything in between.

The FieldFox N9914B is part of Keysight's range of their industry's most versatile portable analysers designed to coordinate with the ever-increasing demands of 5G, satellite communications, signal monitoring and electronic warfare applications. The Keysight FieldFox B-series analysers offer wide-band, gap-free, real-time measurement capabilities that enable 5G network testing in the field.

Contact us for lead time

Contact our team for stock availability and product options.

Price £14,314.56
More Information
Attribute Value
Whats Included
  • AC/DC adapter
  • Localized power cord
  • Rechargeable Li-ion battery
  • LAN cable
  • Soft carrying case with backpack and shoulder straps
  • Quick Reference Guide
Number of Built In Ports 2 ports
Dynamic Range 114 dB
Output Power Up to 1 dBm
Trace Noise 0.0008 dB rms
Applications Cellular
  • 89600 VSA Software
  • Over-The-Air LTE FDD and 5GTF
  • 5G NR
Applications -General Purpose
  • AM/FM Tune and Listen
  • Cable and Antenna Analysis
  • Field Strength Measurement
  • SCPI Code Compatibility
  • Spectrogram
  • Stimulus Response
Applications - Wireless Connectivity 89600 VSA Software
Bandwidth Options 6.5_GHz
DANL @ 1 GHz -163 dBm
Maximum Analysis Bandwidth 120 MHz
Maximum Real Time Bandwidth 120 MHz
Phase Noise @ 1GHz (1 MHz Offset) -124 dBc/Hz
Phase Noise @ 1 GHz (10 kHz Offset) -117 dBc/Hz
Phase Noise @ 1 GHz (30 kHz Offset) -115 dBc/Hz
Standard Attenuator Range 40 dB
Standard Attenuator Step 5 dB
TOI @ 1 GHz (3rd Order Intercept) +11dBm
Instrument Type Combination Analyzer
Additional CAT / VNA Based Features
  • Mixed-Mode S-Parameters
  • DTF/TDR Cable Measurements
  • Vector Voltmeter
Additional SA Based Features
  • Real-Time Spectrum Analysis
  • Noise Figure Measurements
  • Over-The-Air Measurements
  • Built-In Power Meter
  • Extended Range Transmission Analysis (ERTA)
SA Start Frequency 5 kHz
Applications - Digital Video 89600 VSA Software
Key Features

Keysight N9914B Key Features:

  • Standard model includes cable and antenna analyzer (CAT).
  • Capture elusive signals with 100 MHz gap-free, real-time bandwidth.
  • Measure all four S-parameters simultaneously with 115 dB dynamic range.
  • Make accurate spectrum analyser measurements (± 0.3 dB) without warmup.
  • Perform over-the-air measurements for 5G NR and LTE.
  • Use GPS/GNSS for geolocation and timestamping.
  • Carry one lightweight unit at 3.4 kg (7.4 lb).
Maximum Frequency 6.5 GHz
Minimum Frequency 6.5 GHz
