Marki Microwave
High-Linearity Triple-Balanced Mixer
The T3-1040G is a high performance mixer featuring LO/RF from 10 to 40 GHz and IF from 1 to 18 GHz. As with all T3 mixers, this mixer offers unparalleled nonlinear performance in terms of IIP3, P1dB, and spurious performance with a flexible LO drive requirement from +13 dBm to +25 dBm.
The T3-1040G is offered in connectorised and dropin style packaging, suitable for any type of system level integration. The T3-1040G is a form fit function replacement for the obsolete T3-1040, built with GaAs diodes instead of Si.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| IF (GHz) | 1 to 18 |
| LO Drive (dBm) | +13 to +25 |
| Conversion Loss (dB) | 8 |
| Isolations L-R (dB) | 32 |
| RF/LO (GHz) Low | 10 |
| RF/LO (GHz) High | 40 |
| IIP3 (dBm) | +25 |
| Product Type | T3 Mixer |
