TBS1072C

Tektronix

Digital Storage Oscilloscope: 70 MHz bandwidth, 1 GS/s sample rate, 2 Channel

Skip to the beginning of the images gallery

The TBS1000C Series Digital Storage Oscilloscope offers affordable performance in a compact design. It is designed to meet the needs of today's educational institutions, embedded design engineers, and maker community. The instrument includes a 7-inch WVGA color display with up to 1 GS/s sample rate, bandwidths from 50 MHz to 200 MHz and a five-year warranty.

The instrument comes with an innovative courseware system that integrates the lab exercises with step-by-step instructions for use, by the students. HelpEverywhere® system provides useful tips and hints throughout the user interface, to make the instrument more approachable to a new user.

Discover Tektronix's factory service plans

Protect your investment and your uptime with Tektronix's service plans, review each plan and choose which is best for you.

Find out more

[email protected]

+44 330 313 3220

Specifications

More Information
Attribute	Value
Manufacturer Product Family	TBS1000C Digital Storage Oscilloscope
Key Features	Key performance specifications 200 MHz, 100 MHz, 70 MHz, and 50 MHz bandwidth models 2-channel models 1 GS/s sample rate on all channels 20k point record length on all channels Advanced triggers include pulse, runt, and line triggers Five-year warranty 7-inch WVGA color display with 15 horizontal divisions that shows 50% more signal 32 automated measurements Dual window FFT with simultaneous time and frequency domain views Trigger frequency counter Pan and Zoom capability Multi-language user interface with support for 10 languages in the user interface and front panel overlay Small footprint and light weight Fanless design contributes to low noise operation Connectivity USB 2.0 host port on the front panel for quick and easy data storage. USB 2.0 device port on rear panel to connect to a PC and remotely control the instrument. Education HelpEverywhere® provides helpful on-screen tips for users Built-in oscilloscope handbook provides operating instructions and oscilloscope fundamentals Integrated courseware feature provides lab exercise guidance on the display Autoset, Cursors, and Automated measurements can be disabled to help educators to teach basic concepts to students
Sample Rate	1 GS/s
Record Length	20 K points
Bandwidth	70 MHz
Channels	2
Series	TBS1000C
