IR4018-20
IR4018-20
Hioki
Analogue HiTester
This product is available in 5-7 weeks
Reliable and Efficient Insulation Testing in the Field
Hioki insulation testers or megohmmeters feature all-in-one designs including built-in rugged cases and test lead storage compartments. The IR4018-20 is a single-range, 1000V/2000MΩ analogue insulation resistance tester with efficient functions and features to help shorten work time associated with field insulation testing.
CAT III 600 V
Key Features
- Single range testing voltage of 1000 V
- Test insulation resistance up to 2000 MΩ
- Built tough to withstand a 1-meter drop onto a concrete floor
- Bright LED luminous scale
- Check for live circuits and battery status
- Integrated hard case for quick and easy storage without disconnecting the leads
Buy Online
| Attribute | Value |
|---|---|
| Power Supply | LR6 (AA) alkaline batteries ×4, Continuous use: 15 hours (no load) |
| Included Accessories | Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
| Other Functions | Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
| Rated Output Voltage | 1000 V DC |
| AC Voltage range |
0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy, |
| Accuracy 1st effective measuring range MΩ (±4% rdg.) | ±2 % of scale length, 2 M to 1000 MΩ |
| Lower Limit Resistance | 1 MΩ (measurement resistance value to maintain testing voltage) |
| Overload Protection | 1200 V AC (10 sec.) |
| Effective Maximum Indicated Value | 2000 MΩ |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
