PW3365
PW3365
Hioki
Clamp On Power Logger
Eliminate the Risk of Short-Circuits and Electrical Accidents
Hioki Clamp On Power Meters are multi-channel power measuring devices utilizing clamp sensor input to accurately and safely measure power on single-phase to three-phase lines. The PW3365 power logger takes safety and convenience one step further by being the world’s first non-metallic contact power meter that utilizes completely covered voltage clips that can be attached to any part of a cable or busbar. Customers can now monitor power demand and other power parameters to aid in energy audits and validate energy saving measures without risk of short-circuit accidents, power interruptions, or bodily injury due to electrocutions.
Key Features
- Measure voltage from the top of the cable with zero risk of short circuit
- Supports single to three-phase, 4-wire circuits
- Measure between 90 V to 520 V
- Display harmonics up to the 13th order
- Slim, compact design that can be placed anywhere
- Store months of data on SD cards
- QUICK SET function guides you in making the right connections
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Power Supply |
AC adapter Z1008: (100 to 240 V AC, 50 Hz/60 Hz), 45 VA (including AC adapter) |
| Included Accessories | Safety Voltage Sensor PW9020 ×1 set, AC adapter Z1008 ×1, USB cable ×1, Instruction manual ×1, Measurement guide ×1, Color clip (red, yellow, blue and white each 4), Spiral tubes in black (cord bundling for current sensors and voltage sensors) ×10 |
| Interfaces | SD/SDHC memory card, LAN 100BASE-TX: HTTP server function, remote settings via communication program, data download, USB 2.0: When connected to a PC, the SD Card and internal memory are recognized as removable storage devices, remote settings via communication program, data download |
| Measurement Items | Voltage RMS, current RMS, voltage fundamental wave value, current fundamental wave value, voltage fundamental wave phase angle, current fundamental wave phase angle, frequency (U1), voltage waveform peak (absolute value), current waveform peak (absolute value), active power, reactive power, apparent power, power factor (with lag/lead display) or displacement power factor (with lag/lead display), active energy (consumption, regeneration), reactive energy (lag, lead), energy cost display, active power demand quantity (consumption, regeneration), reactive power demand quantity (lag, lead), active power demand value (consumption, regeneration), reactive power demand value (lag, lead), power factor demand |
| Functions | Connection check, Quick Set navigation guide, clock |
| Dimensions and Weight |
180 mm (7.09 in)W × 100 mm (3.94 in)H × 48 mm (1.89 in)D, 540 g (19 oz) without PW9002 |
| Basic Accuracy |
Voltage : ±1.5% rdg. ±0.2% f.s(combined accuracy with PW3365-20 + PW9020) |
| Save Destination | SD/SDHC Memory card, or internal memory at real time |
| Measurement Lines | 50/60 Hz, Single phase 2 wires (1/2/3 circuits), Single phase 3 wires (1 circuit), Three phases 3 wires (1 circuit), Three phases 4 wires (1 circuit), Current only: 1 to 3 channels |
| Voltage Ranges | 400 V AC (Effective measurement range: 90.0 V to 520.0 V) |
| Current Ranges |
500.00 mA to 5.0000 kA AC (depends on current sensor in use), |
| Power Ranges | 200.00 W to 6.0000 MW (depends on voltage/current combination and measured line type) |
| Harmomic | Harmonic voltage, harmonic current, voltage total harmonic distortion (THD-F or THD-R), current total harmonic distortion (THD-F or TDH-R), up to 13th order |
| Display Update Rate | 0.5 sec (except when accessing SD card or internal memory, or during LAN/USB communication) |
| Data Save Interval | 1 sec to 30 sec, 1 minute to 60 minutes, 14 selections |
| Save Items |
Measurement value save: Average only / Average, Maximum, Minimum value |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
