PZ2110A

Precision SMU Expanding Precise Static DC Measurements with the Best-In-Class 10 fA
Resolution to Fast Dynamic Measurements at a 1.25 MSa/s Sampling Rate

The Keysight PZ2110A is a precision source/measure unit (SMU) that expands precise measurements from conventional static measurements with a resolution of 10 fA and 30 fArms noise level with 1 power line cycle (PLC) aperture time (at 50 Hz power line frequency), pulsed measurements with as narrow pulse width as 20 μs, to fast dynamic measurements at a sampling rate of 1.25 MSa/s with its Digitizer Mode.

Its narrow pulse capability enables you to suppress the self-heat effect to reveal the true characteristics of the devices. It covers currents up to 315 mA and voltages up to 210 V for both source and measurement functions, making it ideal for a wide variety of current versus voltage (IV) measurement tasks that require both high resolution and accuracy.

The PZ2110A can accurately perform characterization, parametric tests, and reliability tests of semiconductors, active/passive components, and general electronic devices.
