UNO-2484G
UNO-2484G
Advantech
Modular Compact Embedded Box PC with 6th/7th Gen Intel® Core™ i CPU
Advantech's new generation UNO-2000 series of Embedded Automation Computers are fanless and highly ruggedized with embedded OS. New UNO-2000 series are modular designs which provide flexible and time-to-market support in variety of applications. The series also includes iDOOR technology which supports automation feature-extensions such as multiple I/O peripherals, Industrial Fieldbus, and smart I/O Communication.
New UNO-2000 series including pocket, small, and regular-size form-factors for smart factory applications such as Equipment Connectivity (EC), Process Visualization (PV), Environment Management (EM), and Dispatch Management (DM) solutions.
Key Features:
- Intel® Core™ i7/i5/i3/Celeron Processor with 8GB DDR4 built-in Memory
- 4 x GbE, 4 x USB 3.0, 1 x HDMI, 1 x DP, 4 x RS232/422/485
- Stackable 2nd layer for up to 4 iDoor extension or customize for domain applications
- Compact Fanless Design
- Ruggedized by zero cable and lockable I/O design
- Supports 30+ iDOOR combination with four main categories
- Diverse system I/O and Isolated Digital I/O by iDoor Technology
- Supports Fieldbus Protocol by iDoor Technology
- 3G/GPS/GPRS/Wi-Fi Communication by iDoor Technology with RED Compliance
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries, call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Memory |
i7/i5/i3 model: built-in 8GB DDR4 2133 MHz (supports up to 16GB) |
| USB | 4 x USB 3.0 |
| Serial Ports | 4 x RS-232/422/485, 50–115.2 kbps |
| Mini PCIe |
1 x full-size mPCIe slot (single-stack version; wireless iDoor only) |
| TPM (Optional) | TPM 2.0 (optional) |
| Ethernet | 4 x RJ45, 10/100/1000 Mbps (1000BASE-T) |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
