WISE-2410

WISE-2410 is a LoRaWAN wireless condition monitoring sensor integrated with an ARM Cortex-M4 processor, a LoRa transceiver, a 3-axis accelerometer, and a temperature sensor. It balances wireless bandwidth between the sensor and gateway, mitigating data-transmission failure rates between edge devices and gateways. With on-board edge computing, WISE-2410 calculates complex eigenvalues itself — VRMS, ARMS, Peak, Displacement, Kurtosis, Crest factor, Skewness, and Standard Deviation — balancing the loading between the sensor, gateway, and cloud. Battery-powered with up to a 2-year battery life and an IP66 enclosure, it is ideal for LPWAN applications such as pumps, HVAC systems, motors, and facility monitoring.

Key Features:

• LoRaWAN wireless connectivity
• Built-in 3-axis accelerometer and temperature sensor
• On-board computing: directly sends VRMS, ARMS, Peak, Displacement, Kurtosis, Crest factor, Skewness and Standard Deviation values
• Support battery power supply, no wiring installation needed
• Easy settings with user-friendly interfaces on WISE Studio utility
• ISO 10816/20816 compliant
• Support wide temperature -20 ~ 80°C (battery-powered)
• IP66 enclosure design
