151-CT Series
151-CT Series
Bird RF
150 Watt, Conduction-Cooled Dry Terminations
151-CT Series, RF Terminations are world renowned for their high-quality, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI. The 151 series provides a higher frequency and typically better passive intermodulation performance than the 150-CT series.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
151-CT Series Specifications
- Rugged Reliability provides years of trouble free use
- Conducts heat to user-supplied heat sink
- Low Intermodulation better than -120dBc
- 4 GHz Frequency Range
| Attribute | Value |
|---|---|
| Manufacturer | Bird |
| Impedence Ohm | 50.0000 |
| Housing surface finish | Aluminum, Yellow Irridite |
| VSWR and Frequency Range | DC to 1 GHz @ 1.1:1 max., 1 GHz to 4 GHz @ 1.25:1 max |
| Operating Position | Any |
| Cooling Type | Dry (Conduction-Cooled) |
| Base to Connector Center | 0.52" (13.21mm) |
| Mounting Centers | 1.625" x 0.875", (41.28 x 22.23 mm) |
| Connectors | N |
| Dimensions | (with N connector) 1.9" x 2.0" x 1.1" (L x W x H), 48.26 x 50.8 x 27.94 mm |
