DAQM900A
DAQM900A
Keysight Technologies
DAQM900A 20 Channel Solid-state Multiplexer Module for DAQ970A and DAQ973A
20 Channel Solid-state Multiplexer Module. Scanning speed up to 450 channels per second and built-in thermocouple reference junction.
The Keysight DAQM900A module Data Acquisition System is the fastest switching and scanning multiplexer for general purpose use. It combines dense, multi-function switching with 450 channel/second scan rates to address high speed and high throughput data acquisition applications.
Two- and four-wire channels can be mixed on the same module. Capable of measuring voltage ac/dc, frequency/period, 2/4-wire resistance, and temperature with thermocouple sensors.
Standard Product Includes:
- 1 DAQM900A, 20 Channel Solid-state Multiplexer Module
- 1 Functional Test Certificate
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| For Use With | |
| Speed (ch/sec) | 450 (ch/sec) |
| Key Features |
|
| Channels | 20 |
| Bandwidth | 10_MHz |
| Additional Services | Built-in cold junction reference |
| Product Type | Multiplexer 2 / 4 Wire |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
