ERZ-HPA-3200-3800-40
ERZ-HPA-3200-3800-40
Erzia
Ka Band High Power Amplifier
The ERZ-HPA-3200-3800-40 is a Ka Band high power amplifier providing an output power of 38.5 dBm and a gain of 50 dB. The compact size and modularity makes it ideal for a wide range of applications.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Start (GHz) | 32.0000 |
| Frequency Stop (GHz) | 38.0000 |
| Power Supply (V) | 24± 4V |
| Current (mA) | 3300 |
| Applications |
|
| Storage Temperature | -55°C to 125°C |
| Band | Ka Band |
| Output Power (dBm) | 39 |
| Gain (dB) | 49 |
| Operating Temperature | -35°C to 70°C |
| Connectors | 2.92 mm Female |
| Product Type | High Power Amplifier |
| Dimensions | 100 x 100 x 22 mm |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
