Erzia

X Band Low Band Amplifier

The ERZ-LNA-0850-0960-30-2.5 is a X Band amplifier providing a gain of 31 dB and a noise figure of 2.5 dB. The compact size and modularity makes it ideal for a wide range of applications.
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Applications
  • Industrial
  • Laboratory
  • Satcom
  • Telecom
  • Space
  • Aerospace
  • Military
Frequency Start (GHz) 10.0000
Frequency Stop (GHz) 11.0000
Power Supply (V) 15± 1V
Current (mA) 200
Storage Temperature -55°C to 125°C
Band X Band
Output Power (dBm) 20
Gain (dB) 31
Operating Temperature -40°C to 85°C
Connectors SMA Female
Product Type Low Noise Amplifier
Dimensions 16.3 x 15 x 7.3 mm
More Information
Attribute Value
Data Sheet Click here to view
