gMDR0015 A E-band IQ mod/demod 71-86
Gotmic E-band IQ mod/demod 71-86 GHz
The Gotmic gMDR0015 is a direct IQ modulator or a demodulator that covers the full E-band. Baseband inputs are IQ and IQ complementary signals from DC up to 12 GHz. Both LO and image suppression are excellent throughout the E-band. LO-RF isolation features 30 dB and image suppression 25 dB. LO drive power is at a modest 7 dBm.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Applications |
|
| Storage Temperature | -65 to +150°C |
| Maximum Frequency | 71 GHz |
| Band | E Band |
| Minimum Frequency | 86 GHz |
| Operating Temperature | -40 to + 85°C |
| Product Type | Mixer |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
