HI-8483CLI
HI-8483CLI
Holt Integrated Circuits
HI-8483 Series ARINC 429 Line Receiver
The HI-8483 bus interface unit is a dual differential line receiver in accordance with the requirements of the ARINC 429 bus specification. The device translates incoming ARINC 429 signals to normal CMOS/TTL levels on each of its two independent receive channels. The HI-8483 is a functional alternative to the Fairchild/Raytheon RM3283 and DEI3283.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
HI-8483CLI Specifications
- Replacement for RM3283 and DEI3283
- Converts ARINC 429 Levels to Digital Data
- Input Hysteresis for Superior Noise Rejection
- TTL and CMOS Outputs and Test Inputs
- Industrial & Extended Temperature Ranges Available
- 20-Pin SOIC, DIP & LCC Packages Are Available
| Attribute | Value |
|---|---|
| RoHS | Yes |
| Product Type | ARINC 429 Line Receivers |
| Package Description | 20 Pin Ceramic LCC |
| Product Longevity | > 10 years |
| Applications |
|
| Flow | I |
| Temperature Range | -40°C to +85°C |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
