MEQ10-14ACH
MEQ10-14ACH
Marki Microwave
Passive GaAs MMIC Equaliser (DC - 14 GHz)
The MEQX-14ACH family of passive MMIC equaliser die are an ideal solution for compensating for low pass filtering effects in RF/microwave and high speed digital systems. They provide positive slope from DC to 14GHz with DC attenuation options between 3 and 10dB.
The unique design offers superior return loss to competitors. GaAs MMIC technology provides consistent unit-to-unit performance in a small, low cost form factor.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Return loss | 24 dB |
| Maximum Frequency | 14 GHz |
| Minimum Frequency | DC |
| Applications |
|
| RoHS | Y |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
