MEQ10-30A

MEQ10-30A

Marki Microwave

Passive MMIC Equaliser (DC - 30 GHz)

The MEQ10-30A is a passive MMIC equaliser. It is a positive gain slope equaliser designed to pass DC to 30GHz.

Equalisation can be applied to reduce low pass filtering effects in both RF/microwave and high speed digital systems. Passive GaAs MMIC technology allows production of smaller equaliser constructions that replace larger form factor circuit board constructions.

Better IC tolerances allow for less unit to unit variation that traditionally etched circuits have. Low unit to unit variation allow for accurate simulations using the provided S2P file taken from measured production units.

Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Key Features
  • Insertion loss typically 0.5dB at 30GHz
  • 10dB low frequency attenuation
  • Excellent return loss
  • Broadband Operation
  • RoHS Compliant
Return loss 20 dB
Maximum Frequency 30 GHz
Minimum Frequency DC
RoHS Y
More Information
Attribute Value
Data Sheet Click here to view
