MEQ4-70ACH
MEQ4-70ACH
Marki Microwave
Passive GaAs MMIC 70 GHz Equaliser
Bare Die Passive MMIC Equaliser, 4 dB DC Attenuation
The MEQ4-70ACH passive MMIC Equaliser die is an ideal solution for compensating for low-pass filtering effects in RF/microwave and high-speed digital systems. It provides positive slope from DC to 70 GHz with 4 dB DC attenuation.
The unique design offers superior return loss to competitors. GaAs MMIC technology provides consistent unit-to-unit performance in a small, low-cost form factor.
MEQ4-70ACH Applications:
- RF Transceivers
- High-Speed Data
- Telecom
- Cable Loss Compensation
- Amplifier Compensation
- 5G
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Family | Equalisers |
| Size | 1.25 x 1.1 mm |
| Key Features |
|
| Minimum Frequency | 0 GHz |
| Package | Bare Die |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
