MEQ10-70ACH

MEQ10-70ACH

Marki Microwave

Passive GaAs MMIC 70 GHz Equaliser

Bare Die Passive MMIC Equaliser, 10dB DC Attenuation

The MEQ10-70ACH passive MMIC Equaliser die is an ideal solution for compensating for low pass filtering effects in RF/microwave and high speed digital systems. It provides positive slope from DC to 70GHz with 10 dB DC attenuation.

The unique design offers superior return loss to competitors. GaAs MMIC technology provides consistent unit-to-unit performance in a small, low cost form factor.

MEQ10-70ACH Applications:

  • RF Transceivers
  • High-Speed Data
  • Telecom
  • Cable Loss Compensation
  • Amplifier Compensation
  • 5G
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Product Family Equalisers
Size 1.25 x 1.1 mm
Key Features
  • 4 dB, 6 dB, 8 dB, 10 dB DC attenuation options available
  • Typical insertion loss 1.4 dB at 70 GHz
  • Return loss better than 20 dB over entire band
Minimum Frequency 0 GHz
Package Bare Die
More Information
Attribute Value
Data Sheet Click here to view
