MM1-0222LSM
MM1-0222LSM
Marki Microwave
GaAs MMIC Double Balanced Mixer
The MM1-0222LSM is a GaAs MMIC double balanced mixer that features excellent conversion loss, superior isolations and spurious performance across a broad bandwidth. MM1-0222LSM works well as both an up and down converter through Ku band and beyond.
The MM1-0222LSM is recommend for low power applications that demand high linearity. If higher LO drive is available, the MM1-0222HSM offers higher linearity in the same surface mount package.
The MM1-0222LSM is available in a 3x3 mm QFN package. Evaluation boards are also available
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Applications |
|
| IF (GHz) | 0 to 3.5 |
| LO Drive Min (dBm) | +7 to +15 |
| Conversion Loss (dB) | 7 |
| Isolations L-R (dB) | 50 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| IIP3 (dBm) | +11 |
| Product Type | MMIC/Microlithic Surface Mounts |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
