MM2A-0530HPSM
MM2A-0530HPSM
Marki Microwave
Integrated Drive GaAs MMIC Mixer
The MM2A-0530HPSM is a versatile, robust, and broadband triple balanced mixer with an integrated broadband LO driver amplifier. The MM2A-0530HPSM is ideal for applications with wide and overlapping bandwidths and operation through the K band. The integrated LO driver amplifier allows for operation with LO powers as low as +0dBm while retaining exceptional conversion loss and linearity.
MM2A-0530HPSM Applications:
- Single Sideband and Image Rejection Mixing
- IQ Modulation / Demodulation
- Vector Amplitude Modulation
- Band Shifting
- 5G Band Support
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Family | Mixers |
| Size | 7x7 mm |
| Key Features |
|
| LO Drive Min (dBm) | -3 |
| RF/LO (GHz) Low | 5 |
| RF/LO (GHz) High | 30 |
| IIP3 (dBm) | 25 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
