MMIQA-0626HPSM
MMIQA-0626HPSM
Marki Microwave
Integrated Drive GaAs MMIC IQ Mixer
The MMIQA-0626HPSM is a versatile, robust, and broadband IQ mixer with an integrated broadband LO driver amplifier. The MMIQA-0626HPSM is ideal for IQ, single sideband, and image reject mixing applications with wide bandwidths. The integrated LO driver amplifier allows for operation with LO powers as low as -2dBm while retaining exceptional conversion loss and linearity.
MMIQA-0626HPSM Applications:
- Single Sideband and Image Rejection Mixing
- IQ Modulation / Demodulation
- Vector Amplitude Modulation
- Band Shifting
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Family | IQ Mixers |
| Size | 7x7 mm |
| Key Features |
|
| LO Drive Min (dBm) | -2 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| IIP3 (dBm) | 26 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
