T3-18G
T3-18G
Marki Microwave
Two-Tone-Terminator Mixer
The T3-18G is a high performance mixer featuring LO/RF from 10 MHz to 18 GHz and IF from 1 MHz to 10 GHz. As with all T3 mixers, this mixer offers unparalleled nonlinear performance in terms of IIP3, P1dB, and spurious performance with a flexible LO drive requirement from +15 dBm to +25 dBm.
The T3-18G is offered in connectorised, surface mount, and drop-in style packaging, suitable for any type of system level integration. The T3-18G differs from its sister product the T3-18 in that the T3-18G is built using GaAs diodes instead of Si.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| IF (GHz) | 0.001 to 10 |
| LO Drive Min (dBm) | +15 to +27 |
| Conversion Loss (dB) | 7.5 |
| Isolations L-R (dB) | 25 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| IIP3 (dBm) | +30 |
| Product Type | T3 Mixer |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
