9018-50
9018-50
Hioki
Clamp on Probe
Simply Connect to a Tester or Recorder to Easily Measure Large Currents
Hioki current sensors are best-in-class devices for accurately capturing a wide range of current levels. The 9018-50 is a multi-range 500 A AC voltage output clamp sensor with superior phase characteristics for capturing waveforms with DMMs and Memory HiCorders. Measure AC current on live power lines without needing to cut the wire.
Key Features
- Choose from six general-purpose ranges
- Accurately record and analyze waveforms and harmonic signals
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Included Accessories | Instruction manual ×1 |
| Max Allowable Input | 50 A rms continuous (10/20/50 A ranges) 400 A rms continuous (100/200 A ranges) 650 A rms continuous (500 A range) (For 40 Hz to 100 Hz: 100 %, and for 100 Hz to 1 kHz: within 50 % of derating) |
| Dimensions and Weight | 78 mm (3.07 in) W × 188 mm (7.40 in) H × 35 mm (1.38 in) D, 420 g (14.8 oz), cord length: 3 m (9.84 ft) |
| Rated Current | 20 A to 1000 A AC, 6 ranges |
| Frequency Bandwidth | Add to amplitude accuracy : ± 1% rdg. Add to phase accuracy : ± 2.5° for frequencies from 40 Hz to 3 kHz |
| Output Voltage Rate | 0.2 V AC f.s. (f.s. = setting rage) (Connect to a voltage input device providing a high input impedance of 1 MΩ) |
| Core Diameter | φ46 mm (1.81 in) |
