Hioki 9320-01 Logic Probe | APC Technology Group

9320-01

9320-01

Hioki

Logic Probe

Detect the Presence of Voltage or Relay Contact Signals with Memory HiCorders

Key Features

  • 4 input channels (Not isolated)
  • For ON/OFF detection of voltage/contact signals
  • Select from 3 steps of input thresholds
  • Response pulse width of 500 ns or more
  • Compatible with Memory HiCorders featuring a miniature terminal
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Function Detection of voltage signal or relay contact signal for High/Low state recording
Dimensions and Weight 62 mm (2.44 in)W × 94 mm (3.70 in)H × 20 mm (0.79 in)D, 150 g (5.3 oz), Main unit cable 1.5 m (4.92 ft), input section cable 300 mm (0.98 ft)
Included Accessories IC clip leads ×1, Alligator clip leads ×1, Carrying case ×1, Instruction Manual ×1
Max Allowable Input 0 to +50V DC (the maximum voltage that can be applied across input pins without damage)
Digital Input Threshold 1.4V/ 2.5V/ 4.0V
Contact Input Detection Resistance

1.4 V: 1.5 kΩ or higher (open) and 500 Ω or lower (short)
2.5 V: 3.5 kΩ or higher (open) and 1.5 kΩ or lower (short)
4.0 V: 25 kΩ or higher (open) and 8 kΩ or lower (short)

Detectable Pulse Width 500 ns or longer
More Information
Attribute Value
Data Sheet Click here to view
