9010/60P
9010/60P
Narda Safety Test Solutions
Full/Pre Compliance Receivers
The 9010/60P receiver, is fully compliant in accordance with the CISPR 16-1-1 in the band A and B and pre compliance
Narda-PMM has developed new EMI / EMC receivers based on an innovative concept and a revolutionary approach to meet the needs of small and medium-sized laboratories that do not find it convenient to invest in a receiver conforming to the CISPR 16-1-1 also for radiated measurements.
They are a perfect mix of full and Pre-Compliance to meet, in a perfect way, the requirements of practical tests, not excluding the possibility of future upgrades to 100% Full-Compliant to CISPR 16-1-1 up to 3, 6 or 18 GHz the simple addition of an external unit, the receiver is connected via Fibre optic cable.
Receivers 9010/xxp are available in the following versions:
- 9010/03P, 10 Hz – 300 MHz
- 9010/30P, 10 Hz – 3 GHz
- 9010/60P, 10 Hz – 6 GHz
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Range |
30 MHz to 3 GHz |
| RF Input |
RF Input: Zin 50 Ω, N fem. VSWR 10 dB RF att.: < 1,2, < 2,0 over 1 GHz 0 dB RF att.: < 2,0, < 3,0 over 1 GHz Attenuator: 0 dB to 55 dB (5 dB steps) Pulse limiter: n.a. Preamplifier gain: n.a. |
| Max Input Level |
Max input level: (without equipment damage) Sinewave AC voltage: 137 dBμV (1 W) Pulse spectral density: 97 dBμV/MHz |
| Preselector |
Preselector: n.a. |
| IF Bandwidth |
Standard 3/6 dB: (6 dB BW) 3, 10, 30, 100, 300 kHz, 1 MHz CISPR-16-1-1: 120 kHz MIL-STD-461 (option): 100 kHz, 1 MHz |
| Noise Level |
30 MHz to 300 MHz < 10 dBμV (QP) (120 kHz RBW) < 7 dBμV (AV) 300 MHz to 3 GHz < 13 dBμV (QP) (120 kHz RBW) < 7 dBμV (AV) 3 GHz to 6 GHz < 15 dBμV (QP) (120 kHz RBW) < 10 dBμV (AV) |
| Measuring Detectors | Peak, Quasi-Peak, Average, RMS, RMS-Average(Optional), CISPR-Average, APD and Smart Detector function |
| Level Measuring Time |
Peak, Quasi-Peak, AVG, RMS (simultaneous detectors): 1 ms to 30 s. (CISPR 16-1-1 default) |
| Display Units |
dBm, dBμV (as stand-alone); |
| Spurious Response | < 10 dBμV, < 15 dBμV over 2 GHz |
| Measurement Accuracy |
30 MHz to 1 GHz ± 1,0 dB S/N > 20 dB: 1 GHz to 3 GHz ± 1,5 dB 3 GHz to 6 GHz ± 2,0 dB |
| I/O Interface | USB 2.0 (rear), USB 2.0 (front; only for future implementation), RS-232, high-speed optical link (2 channels; 2nd channel for future implementation), user port (for LISN connection, etc.), IEEE-488 (GPIB) optional |
| Operating Temperature | 0 °C to 40 °C |
| Power Supply | 10 - 15 Volt DC, 2,5 A; optional Li-ion interchangeable battery (8h use, typical) |
| Dimensions | 235 x 105 x 335 mm |
| Weight | 4.1 kg |
| Demodulation | Built-in AM demodulator (headphone jack) |
| RF Output |
RF output (tracking generator): Zout 50 Ω, BNC fem. |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
