2290-5

2290-5

Keithley Instruments

5 kV Power Supply, 120 VAC Nominal Input Voltage

Series 2290 High Voltage Power Supplies facilitate high voltage device and material testing, as well as high energy physics experimentation. The 2290-5 5kV Power Supply provides voltage outputs up to 5000 V and has a 5 mA current capacity. These supplies measure both output voltage with 1V resolution and output current with 1 µA resolution. In addition to the voltage and current output displays, a third display shows one of four settings: output voltage, voltage limit, current limit, or current trip. These values can be set precisely with the front panel keypad.

The settings can also be programmed over the IEEE-4888 interface, or the output voltage can be set with an analogue control voltage.

Contact us for lead time

Contact our team for stock availability and product options.

Price £4,840.00

Discover Tektronix's factory service plans

Protect your investment and your uptime with Tektronix's service plans, review each plan and choose which is best for you.

More Information
Attribute Value
Key Features
  • Source voltages up to 5 kV
  • 1 µA current measurement resolution
  • Low noise for precision sourcing and sensitive measurements; selectable filters reduce noise to less than 3 mVRMS on the 5 kV supply
  • Safety interlock controls high voltage output
  • IEEE-488 programmable
  • Protection module prevents damage to low voltage instrumentation
Manufacturer Product Family Keithley 2290 Series
Maximum Voltage 5000V
Maximum Current 5mA
Outputs Single Output
Applications
  • High voltage device breakdown testing
  • High voltage component testing
  • Insulation testing
  • High voltage resistivity measurements
  • High energy physics research
More Information
Attribute Value
Data Sheet Click here to view
