ADM-5974CH
ADM-5974CH
Marki Microwave
Broadband Distributed Amplifier
The ADM-5974CH is a broadband, moisture resistant MMIC LO buffer amplifier. The ADM-5974 provides efficient, optimized LO drive to all Marki mixers in band with no required negative bias or sequencing. It is built with a moisture resistant pHEMT process to allow the bare chip to pass biased HAST testing without a hermetic seal. Second harmonic rejection can be tuned to very low levels using the optional negative bias. The ADM-5974 can also be used as a broadband signal amplifier. The bare die features enhanced moisture resistance for improved reliability.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | DC |
| Minimum Input Power for Saturation [dBm] | +6 |
| Maximum Input Power for Saturation [dBm] | +16 |
| Saturated Output Power [dBm] | +22 |
| Small Signal Gain [dB] | 14 |
| OIP3 [dBm] | +27 |
| Amplifier Type | LO Driver Bare Die/Modules |
| Package | Bare Die |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
