HI-3624(A)
HI-3624(A)
ETS-Lindgren
Survey Meter
The ETS-Lindgren HI-3624(A) ELF Magnetic Field Survey Meter is an affordable, easy to use magnetic meter for both field and laboratory measurements.
The standard configuration provides a wide 30 – 2000 Hz frequency response with stable readings when probing for peak field orientations. The 2 kHz upper cut-off frequency allows accurate measurements of more than 30 harmonics of a 60 Hz- power frequency field.
The HI-3624(A) is configured to meet the Swedish requirements for ELF magnetic field measurements. A low frequency cut-off switch enables either the 30 – 2000 Hz response for field testing or the 5 – 2000 Hz response as specified by the Swedish testing protocol for office equipment. The monotropic (simple axis) field sensor allows the user to predict the magnetic field polarization.
Key Features:
- Single axis magnetic sensor
- Measure fields up to 20 G
- Useful directional diagnostic facility
- Electricity supply industry applications
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Response |
HI3624A: 30 – 2000 Hz and 5 – 2000 Hz ± 3 dB, Switch Selectable |
| Frequency Range | 5 (30) Hz – 2000 Hz |
| Sensors | 0.01 m2 nominal area |
| Dynamic Range | 0.2 mG – 20 G |
| Product Category | Survey Meter |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
