ERZ-HPA-2700-3100-43-C
ERZ-HPA-2700-3100-43-C
Erzia
Ka Band High Power Amplifier
The ERZ-HPA-2700-3100-43-C is a high power amplifier based in GaN, providing a gain of 51 dB with a Psat of 42 dBm. The compact size and modularity makes it ideal for a wide range of applications.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Start (GHz) | 27.5 |
| Frequency Stop (GHz) | 31.0000 |
| Power Supply (V) | 28± 4V |
| Current (mA) | 3200 |
| Storage Temperature | -55°C to 125°C |
| Band | Ka Band |
| Output Power (dBm) | 42 |
| Gain (dB) | 51 |
| Operating Temperature | -40°C to 85°C |
| Connectors | 2.92 mm Female |
| Product Type | High Power Amplifier |
| Applications |
|
| Dimensions | 100 x 100 x 21 mm |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
