Electric Field Probe with Field-Replaceable Battery
Electric Field Probe with Field-Replaceable Battery
The HI-6053 Electric Field Probe is a fully intelligent sensor providing broadband frequency coverage, wide dynamic range, and fast, accurate EMF measurements for a variety of field monitoring applications. It operates as a single-range reading probe, allowing continuous data collection across the entire dynamic range, with values available individually or summed for each axis (X, Y, Z).
User-replaceable/rechargeable batteries and optical connectivity, along with compatibility with EMCenter™ platforms or HI-4413P/HI-4413USB interfaces, ensure flexible deployment and system integration.
Key Features:
- Frequency Response: 10 MHz to 40 GHz
- Dynamic Range: 2.0 to 800 V/m
- Provides Individual and Summed Axis Values
- User Replaceable/Rechargeable Batteries
- A2LA Accredited Calibration Report
- Suitable for MIL Standard Specs- MIL-STD 461F Radiated Susceptibility (RS) Suitable for Automotive Specs- SAE J1113/27- GMW 3091/3097/3103- FORD FMC 1278
- Suitable for Commercial Specs- EN/IEC61000-4-3 Radiated Immunity
- HI-4413P Fiber to Serial Converter (Option)
- HI-4413USB Fiber to USB Converter (Option)
- H-491269 Probe Stand Assembly (Option)
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Dimensions | 43.8 cm x 5.7 cm (17.24 in x 2.24 in) |
| Linearity | 0.5 dB (2 to 800 V/m) |
| Isotropic Deviation | 1.0 dB < 18 GHz |
| Maximum Frequency | 1 GHz |
| Minimum Frequency | 10 kHz |
| Configuration |
|
| Frequency Response |
10 MHz to 100 MHz +3.0, -4.0 dB 100 MHz to 1 GHz +3.0, -0.5 dB 1 GHz to 18 GHz +4.0, -2.0 dB 18 GHz to 40 GHz +3.5, -4.5 dB |
| Frequency Range | 10 kHz to 1 GHz |
| Dynamic Range | 2.0 to 800 V/m (Single Range) |
| Overload | >1500 V/m CW |
| Internal Battery |
NiMH AAA, > 30 Hours of continuous operation Battery Charger: 100-240 VAC Universal Input; 3-Hour Charge from Full Depletion |
| Resolution | 0.01 V/m |
| Sampling Rate | 70 Samples/Second Maximum |
